Model No.: HA 217
Certification: API, Other
Type: Center Drill Bit
Material: Tungsten Carbide
Use: Well Drilling
Advantage: High Efficiency Ecnomic
Size: 444.5mm 17 1/2"
Tread: 7 5/8“ Reg Pin
Bearing Type: Journal Or Roller Bearing
Sealed Type: Metal / Rubber Sealed / Open
Protection: Gauge And Shirttail Protection
Certificate: ISO 9001
Packaging: 1 pc per Wooden case
Productivity: 300pcs per month
Place of Origin: Hebei
Supply Ability: 300pcs per month
Certificate: ISO 9001
HS Code: 82071990
We are emerged as the best manufacturer and supplier of Steel Tooth Tricone Bit . These bits are designed for very soft to medium hardness formations with advanced technology to manufacture the best quality product for our reputed clients. Milled Teeth Tricone Bit wear resistance of teeth is enhanced with premium tungsten carbide hardfacing on the tooth surfaces for steel tooth bit. Mill tooth Tricone Bit with high precision roller bearing with two thrust faces. Ball lock the cone.Thrust faces hardface with wear resistant alloy.
The feature of HA127 tricone bit
Basical Parameter Bit Size 17 1/2"(444.5MM) IADC Code HA 127 Connection 7 5/8"API reg pin Nozzle Qty 3NZ Make up Torque(KN.m) 46.1~54.2 Operating Parameter Rotary Speed(rpm) 150~70 Weight on Bit(KN/MM) 0.3-0.75 Formation Very soft formation with low compressive strength ,and high drillability ,such as clay, mudstone,chalk,etc.
7 5/8"API reg pin
Make up Torque(KN.m)
Weight on Bit(KN/MM)
Very soft formation with low compressive strength ,and high drillability ,such as clay, mudstone,chalk,etc.
My company informationHejian Deris Petroleum Drilling Equipment Co., Ltd. Established in 2000 . Have 7 years export experienced . Both Professional Manufacturer and Supplier engaged in 3 " to 26" Tricone bit, 3 " to17 1/2" PDC Bit , 300mm to 2000mm Hole Opener ,Core Barrel, Single Cone Bit ,roller cone bits , Drag Bit and Drill Pipe etc other Drilling Tools .
Products are widely used in petroleum, natural gas, hydrological address, ore drilling ,water well project , no-dig / Trenchless,Piling project .
Introducing the latest technology, advanced production equipment, Perfect testing system to e nsure superior quality .The company has a group of experienced designers and engineers who provide specialized solutions in the field of drilling.
Over the years, the high quality products have been exported to more than 30 countries and regions such as the United States, Canada, Germany, Iran, Qatar, Chile and Southeast Asia at reasonable prices.
Package and shipping
Package Type : wooden case ,also be packaged according to customers requirement
Transportation : by sea , by air or land transportation . Less than 50kg shipping by courier better
Delivery : If we have stock, the delivery time will need about 2~3 working days. In general, common size tricone bits and pdc bit, we have stock.
If we have no stock, such as the tci reamer and PDC Hole Opener, it will be 7-10 working days in total.
If you are interested in our products please feel free to contat with us
How to complete the whole deal
1. Firstly decide the design, material and color
2. Decide the size in accordance with client's requirement and our recommendation
3. We will give the best offer.
4. Client's accept the offer and we send proforma invoice.
5. Client transfers 30%-50% deposit and production begins
6. After production, we will send ready products photo
7. After client's confirmation, we will arrange shipment, and send copy shipping documents like B/L,
commercial invoice and packing list
8. Client transfer balance payment and we will send original documents by express or Telex Release
1 We are manufacture can supply good quality goods and competitive price
2 We not only have ourselves design but also can accept customization
3 We have fast and on time delivery time
4 Every bits have it's quality assurance
5 Contact our anytime if you have any question with bits.
6 Technical supply online
